Item No :
Tunnel pipes withstand severe cold, Huanrui electricOrder(MOQ) :
Tunnel pipes withstand severe cold, Huanrui electric
| Top Selling | Cheap Discount | Adjustable Multiple Profile |
| Suitable for 1-3 floors building | Suitable for beginners | Suitable for multiple floor building |
Profile Dimensions
Profiles can be designed according to customers requirements
| Project | Yield Strength (MPa) | Thickness (mm) | Width (mm) | Surface Treatment |
| C63-200 | Q300-Q550 | 0.75-1.6 mm | 152-300 mm | Galvanized / Galvalume / Zinc-Aluminum-Magnesium coated |
| Item | Details |
| Model | C63-200 |
| Equipment Size | 8600x1300x1600 mm |
| Equipment Weight | Approx. 10T |
| Forming Method | 16 groups + Shaping |
| Transmission Method | Gear + Sprocket drive |
| Main Motor | 20.5kW Servo Motor |
| Rollers | Material: SKD11 die steel |
| Main Shaft | Material: 40Cr |
| Forming Speed | 2700m/hour (excluding punching & cutting) |
| Production Capacity | 4-4.5T/8 hours (average speed) |
| Hole Distance Tolerance | ±0.5mm |
| Nail Hole Height Error | ≤0.5mm |
| Length Tolerance | ±0.75mm |
Machine Components
|
No.
|
Items
|
Quantity
|
|
1
|
Steel Strip Uncoiler
|
1
|
|
2
|
Roll Former Machine
|
1
|
|
3
|
Hydraulic Puncher/Cutter
|
21
|
|
4
|
Hydraulic Station
|
1
|
|
5
|
Design Software
|
1
|
|
6
|
Controlling System
|
1
|
|
7
|
Label Printer
|
1
|
|
8
|
Layout Table
|
1
|
Service
1. Factory Lifetime Service:offer technical support for the entire life of our machines.
2. Customized Profile:can design the profile according to customer request.
3. One-Year Guarantee Period:we could supply you the replacement parts free of charge for any damaged parts caused by quality problems.
4. Overseas Services Optional:we can send our technicians to install and train the workers in the clients' factories with extra cost.
Shipping
For different machines or production line parts, we have different packing solutions:
- For the machine or production line, we will use plastic film to cover and wrap. Then will be loaded to the container by forklift or crane.
- For the key parts such as the roll forming rollers set, we will use the metal frame to package.
All Steadily fastened in the container in a suitable manner with steel ropes and locks, being suitable for long-distance transportation.
Customization options Customized logo (Min. order: 1 set) Customized packaging (Min. order: 1 set) Graphic customization (Min. order: 1 set) Color (Min. order: 1 set)
